Diaphragm Valves
Speciality Valves

Diaphragm Valves

Rubber and PTFE lined diaphragm valves ideal for corrosive fluids, slurries and hygienic applications. No stem packing eliminates leakage to atmosphere.

Body Material
CI, DI, SS with lining
Pressure Rating
PN10 – PN16
Size Range
½" – 12"
Lining
EPDM, Butyl, Neoprene, PTFE
Request Quote Download Datasheet
Technical Specifications

Engineered to international standards.

Body Material
CI, DI, SS with lining
Pressure Rating
PN10 – PN16
Size Range
½" – 12"
Lining
EPDM, Butyl, Neoprene, PTFE
End Connections
Flanged, Threaded
Types
Weir, Straight-through
Product

Features

  • No stem packing — zero external leakage
  • Replaceable diaphragm
  • Weir or KB (straight-through) body
  • Suitable for slurries and viscous fluids
Product

Applications

  • Pharmaceutical & biotech
  • Food & beverage
  • Slurry service
  • Mildly corrosive chemicals
Product

Benefits

  • Hygienic dead-space-free flow
  • Simple maintenance — diaphragm-only replacement
  • Excellent for shear-sensitive fluids
